10-teiliges Spiralbohrerset
DIN 338 N, HSS geschliffen
mit abgesetztem Zylinderschaft
in Two-Tone Optik übersichtlich
in einer Metall Kassette
3 - Flächenschaft
Hammerbohrer-Meißel Set - 13-teilig in einem stabilen roten Koffer
mit SDS-Plus-Aufnahme
Inhalt:
10 St. SDS-Plus Hammerbohrer je 1 St. - 5 mm x 110 mm je 1 St. - 6 - 8 - 10 mm x 160 mm je 1 St. - 8 - 10 - 12 mm x 210 mm je 1 St. - 10 - 12 - 14 mm x 240 mm
3 St. SDS-Plus Meißel 1 St. Spitzmeißel - 14 x 250 mm 1 St. Flachmeißel - 14 x 22 x 250 mm 1 St. Kanalmeißel - 14 x 250 mm
Anwendung: Geeignet zum Einsatz mit Bohrhämmern aller Arten in Beton, Klinker, Marmor, Stein und Mauerwerk
19-teiliger Satz HSS-GK RATIO Spiralbohrer DIN 338, Typ N-UNI, rechts, in Rose-Kunststoffkassette
mit Zylinderschaft, kurze und 2-Farbige (gold finish/schwarz) Ausführung
profi lgeschliffene Qualität, Kreuzanschliff ab 3,0 mm Ø,
Spitzenwinkel 130°
1,0 - 10,0 x 0,5 mm steigend
Anwendungsgebiet
Universell einsetzbar, kurz- und langspanend, bedingt auch in VA. Aufgrund der Geometrie geringer Bohrerdruck erforderlich
19-pieces HSS-GK RATIO twist drills DIN 338, type N-UNI, right hand
with straight shank, short and 2-color (amber(gold finish)/black flute) finish
profile ground quality, with split point from 3,0 mm Ø and above
point angle 130°
1,0 - 10,0 x 0,5 mm increments
Range of applications
Universally applicable partlysuitable for long- and short-chip materials, VA materials only to a limited extent.
Import-Kassette
19-tlg. Spiralbohrer-Satz, DIN 338N, HSS, TIN-beschichtet
geschliffene Qualität
in Metallkassette, Farbe: Grau
118° Spitzwinkel
Größen: 1,0 - 10, 0 mm x 0,5 mm
24-tlg. PROFI-Spiralbohrer-Satz, DIN 338, HSSG, Typ N, rechts, in Industrie-Kassette
profilgeschliffene, blanke Spitzenqualität,mit Kreuzanschliff ab 2,0 mm Ø
Inhalt:
24 St. Spiralbohrer HSSG, DIN 338 N, 1 - 10,5 x 0,5 mm steigend + Kernlochmaße 3,3 - 4,2 - 6,8 - 10,2 mm
Anwendungsgebiet
Standardbohrer zum Bohren vonStahl und Stahlguss (legiert undunlegiert), Grauguss, Temperguss,Sphäroguss, Sintereisen, Neusilber, Graphit.
with straight shank, jobbers length, bright finish,profie ground high quality, with split pointfrom 2,0 mm Ø and above, point angle 118°
Range of applicationsStandard drills for drilling steel and cast, alloyed andnon-alloyed, grey cast iron sintered powder metal,german silver, graphite.
in Profi -Metal-Box, 24-pieces, 1,0 - 10,5 x 0,5 mm increments+ core hole drills 3,3 - 4,2 - 6,8 - 10,2 mm
24-tlg. Super-Spiralbohrer-Satz in Rose-Kunststoffkassette,profilgeschliffen, blank, mit Kreuzanschliff ab 2,0 mm Ø, rechts
Inhalt:24 St. Spiralbohrer HSS DIN 338 N, 1 - 10,5 x 0,5 mm steigend, Kernlochmaße 3,3 - 4,2 - 6,8 - 10,2 mm
Anwendungsgebiet
Standardbohrer zum Bohren vonStahl und Stahlguss (legiert undunlegiert), Grauguss, Temperguss,Sphäroguss, Sintereisen, Neusilber, Graphit.
with straight shank, jobbers length, bright finish,profile ground high quality, with split pointfrom 2,0 mm Ø and above, point angle 118°
Range of applicationsStandard drills for drilling steel and cast, alloyed andnon-alloyed, grey cast iron sintered powder metal,german silver, graphite.
in Rose-Box, 24-pieces, 1,0 - 10,5 x 0,5 mm increments+ core hole drills 3,3 - 4,2 - 6,8 - 10,2 mm
25-teiliger Satz HSS-GK RATIO Spiralbohrer DIN 338, Typ N-UNI, rechts, in Rose-Kunststoffkassette
mit Zylinderschaft, kurze und 2-Farbige (gold finish/schwarz) Ausführung
profi lgeschliffene Qualität, Kreuzanschliff ab 3,0 mm Ø,
Spitzenwinkel 130°
1,0 - 13,0 x 0,5 mm steigend
Anwendungsgebiet
Universell einsetzbar, kurz- und langspanend, bedingt auch in VA. Aufgrund der Geometrie geringer Bohrerdruck erforderlich
25-pieces HSS-GK RATIO twist drills DIN 338, type N-UNI, right hand
with straight shank, short and 2-color (amber(gold finish)/black flute) finish
profile ground quality, with split point from 3,0 mm Ø and above
point angle 130°
1,0 - 13,0 x 0,5 mm increments
Range of applications
Universally applicable partlysuitable for long- and short-chip materials, VA materials only to a limited extent.
25-tlg. Super-Spiralbohrer-Satz in Rose-Kunststoffkassette,profilgeschliffen, blank, mit Kreuzanschliff ab 2,0 mm Ø, rechts
Inhalt:25 St. Spiralbohrer HSS DIN 338 N, 1 - 13 x 0,5 mm steigend
Anwendungsgebiet
Standardbohrer zum Bohren vonStahl und Stahlguss (legiert undunlegiert), Grauguss, Temperguss,Sphäroguss, Sintereisen, Neusilber, Graphit.
With straight shank, jobbers length, bright finish,profile ground high quality, with split pointfrom 2,0 mm Ø and above, point angle 118°
Range of applicationsStandard drills for drilling steel and cast, alloyed andnon-alloyed, grey cast iron sintered powder metal,german silver, graphite.
in Rose-Box, 25-pieces, 1,0 - 13,0 x 0,5 mm increments
25-tlg. PROFI-Spiralbohrer-Satz, DIN 338, HSSG, Typ N, rechts, in Industrie-Kassette
profilgeschliffene, blanke Spitzenqualität,mit Kreuzanschliff ab 2,0 mm Ø
Inhalt:
25 St. Spiralbohrer HSSG, DIN 338 N, 1 - 13,0 x 0,5 mm steigend
Anwendungsgebiet
Standardbohrer zum Bohren vonStahl und Stahlguss (legiert undunlegiert), Grauguss, Temperguss,Sphäroguss, Sintereisen, Neusilber, Graphit.
with straight shank, jobbers length, bright finish,profile ground high quality, with split pointfrom 2,0 mm Ø and above, point angle 118°
Range of applicationsStandard drills for drilling steel and cast, alloyed andnon-alloyed, grey cast iron sintered powder metal,german silver, graphite.
in Profi -Metal-Box, 25-pieces, 1,0 - 13,0 x 0,5 mm increments
Industrie-Kassette
25-tlg. Spiralbohrer-Satz, DIN 338N, HSS TIN, TITAN-beschichtet
mit Zylinderschaft, kurze Ausführung
profilgeschliffene Qualität
mit Kreuzanschliff ab 3,0 mm
in Metallkassette, Farbe: BLAU
118° Spitzwinkel
Größen: 1,0 - 13,0 x 0,5 mm
gerade genutet, 4-12/1mm - 4-20/2mm - 6-30/2mm
in Rose-Kunststoffkassette, 3-teilig
mit Zylinderschaft, 5% cobaltlegiert, blanke Ausführung,mit KreuzanschliffAnwendungsgebietZur Bearbeitung von Nichteisen-Metalle, Edelstahlbleche,thermoplastische und duroplastische Kunststoffe sowie allegängigen Stahlbleche bis zu einer Dicke von 4,0 mm.Mit diesem Werkzeug können in einem Arbeitsgang Blechezentriert, angebohrt, aufgebohrt und entgratet werden
HSS-Co Step drills spiral flute
with straight shank, 5% cobalt alloyed, bright finish,with split pointRange of applicationsFor sheet metal working. Suitable for all standard industrialmaterials: nonferrous metal, special steel, thermoplastics andduroplastics as well as sheet metals up to 4,0 mm thickness.This tool will center, spot-drill, bore and debure – all in onesmooth, high performance working cycle.
in Rose-Box, 3-pieces 4-12/1mm - 4-20/2mm - 6-30/2mm
spiral genutet, 4-12/1mm - 4-20/2mm - 6-30/2mm
in Rose-Kunststoffkassette, 3-teilig
mit Zylinderschaft, 5% cobaltlegiert, blanke Ausführung,mit KreuzanschliffAnwendungsgebietZur Bearbeitung von Nichteisen-Metalle, Edelstahlbleche,thermoplastische und duroplastische Kunststoffe sowie allegängigen Stahlbleche bis zu einer Dicke von 4,0 mm.Mit diesem Werkzeug können in einem Arbeitsgang Blechezentriert, angebohrt, aufgebohrt und entgratet werden
HSS-Co Step drills spiral flute
with straight shank, 5% cobalt alloyed, bright finish,with split pointRange of applicationsFor sheet metal working. Suitable for all standard industrialmaterials: nonferrous metal, special steel, thermoplastics andduroplastics as well as sheet metals up to 4,0 mm thickness.This tool will center, spot-drill, bore and debure – all in onesmooth, high performance working cycle.
in Rose-Box, 3-pieces 4-12/1mm - 4-20/2mm - 6-30/2mm
Sonderposten 12 - 16 - 20 mm Länge: 1000 mmSDS-Plus Hammerbohrer Satz 3-teilig
mit kräftiger Hartmetall - Platte und Wendel
Größen: je 1 St. 12 - 16 - 20 mm x 1000 mm
Länge: 1000 mm
Anwendung:für Beton - Mauerwerk - Naturstein
HSS-STANDARD-Blechschälbohrer mit Kreuzanschliff, TIN-beschichtetRose-Kunststoffkassette, 3-teilig 3-14 mm - 8-20mm - 16-30,5 mm
mit Zylinderschaft
AnwendungsgebietZur Blechbearbeitung sowie alle gängigen Industriematerialienz.B. Edelstahlbleche, Nichteisen-Metalle undalle gängigen Stahlbleche bis zu 4 mm.
HSS RATIOLINE® Rotary Drill Sheet
with straight shank, TIN coated,with split pointRange of applicationsFor sheet metal and all common industry materials,for example stainless steel sheets, non metals andall common steel sheets up to 4 mm.
TIN-coated, in Rose-Box, 3-pieces 3-14 mm - 8-20mm - 16-30,5 mm
32-tlg. Bohrer-, Senker- und Gewindeschneider-Setin ROSE-KassettenBox links:Spiralbohrer DIN 338Ø 1,0 - 10 mm (0,5 mm steigend)Box in der Mitte:Gewindeschneider DIN 371B - M3 M4 M5 M6 M8 M10 + DIN 376B - M 12Box rechtsKegelsenker 90° DIN 3356,3 8,3 10,4 - 12,4 - 16,5 - 20,5 mm
3er Set Anti Vibration Kegelsenker aus HSS-E05 - Ungleiche Teilung, X5 Cut beschichtet
Ø 10,4/16,5/25,0 mm
Ungleichmäßige Schneidenaufteilung
Vibrationsfrei für bessere Oberflächen
Exzentrischer Hinterschliff und konstantes Profil
Hochpositiver Schnitt für extreme Laufruhe
Oberfläche blank bzw. X5.Cut beschichtet
Set HSS-E05 Counter Sinks - Unequal Division, X5 Cut coated
Ø 10,4/16,5/25,0 mm
Unequal division of flutes
No vibrations, better surface quality
Excentric relief and constant profile
High positive cut for chatter free working
Bright finish or with X5.Cut coating
3er Set Anti Vibration Kegelsenker aus HSS-E05 - Ungleiche Teilung, X5 Cut beschichtet
Ø 8,3/12,4/20,5 mm
Ungleichmäßige Schneidenaufteilung
Vibrationsfrei für bessere Oberflächen
Exzentrischer Hinterschliff und konstantes Profil
Hochpositiver Schnitt für extreme Laufruhe
Oberfläche blank bzw. X5.Cut beschichtet
Set HSS-E05 Counter Sinks - Unequal Division, X5 Cut coated
Ø 8,3/12,4/20,5 mm
Unequal division of flutes
No vibrations, better surface quality
Excentric relief and constant profile
High positive cut for chatter free working
Bright finish or with X5.Cut coating
DIN 206 Form B HSS-Handreibahlen-Satz (41-teilig)
Inhalt:je 1 St. Handreibahle Ø 6,0 - 10,0 mm, um 0,1 mm steigendToleranz H7, mit Zylinderschaft und Vierkant spiral genutet, in Kunststoffbox (blau)
Deutsche Produktion
41-tlg. PROFI-Spiralbohrer-Satz, DIN 338, HSSG, Typ N, rechts, in Industrie-Kassette
profilgeschliffene, blanke Spitzenqualität,mit Kreuzanschliff ab 2,0 mm Ø
Inhalt:
41 St. Spiralbohrer HSSG, DIN 338 N, 6 - 10,0 x 0,1 mm steigend
Anwendungsgebiet
Standardbohrer zum Bohren vonStahl und Stahlguss (legiert undunlegiert), Grauguss, Temperguss,Sphäroguss, Sintereisen, Neusilber, Graphit.
with straight shank, jobbers length, bright finish,profile ground high quality, with split pointfrom 2,0 mm Ø and above, point angle 118°
Range of applicationsStandard drills for drilling steel and cast, alloyed andnon-alloyed, grey cast iron sintered powder metal,german silver, graphite.
in Profi -Metal-Box, 41-pieces, 6,0 - 10,0 x 0,1 mm increments
41-tlg. Super-Spiralbohrer-Satz in Rose-Kunststoffkassette,profilgeschliffen, blank, mit Kreuzanschliff ab 2,0 mm Ø, rechts
Inhalt:41 St. Spiralbohrer HSS DIN 338 N, 6 - 10,0 x 0,1 mm
Anwendungsgebiet
Standardbohrer zum Bohren vonStahl und Stahlguss (legiert undunlegiert), Grauguss, Temperguss,Sphäroguss, Sintereisen, Neusilber, Graphit.
Rose-Kunststoffkassette
with straight shank, jobbers length, bright finish,profile ground high quality, with split pointfrom 2,0 mm Ø and above, point angle 118°
Range of applicationsStandard drills for drilling steel and cast, alloyed andnon-alloyed, grey cast iron sintered powder metal,german silver, graphite.
in Rose-Box, 41-pieces, 6,0 - 10,0 x 0,1 mm increments
43-tlg. Gewindeschneidsatz HSSG, DIN 352, M3 - M12, im Kunststoffmagazin
Inhalt:
je 3 St. Handgewindebohrer HSSG, DIN 352 - M3 M4 M5 M6 M8 M10 M12
je 1 St. Schneideisen HSSG, DIN EN 22568 B, für metrisches ISO-Gewinde - M3 M4 M5 M6 M8 M10 M12
5 St. Schneideisenhalter
1 St. Lehre
2 St. Windeisen
7 St. Spiralbohrer DIN 338, HSS GK, geschliffen, mit Kreuzanschliff ab 2 mm
Wir präsentieren einen Gewindeschneidsatz, für höchste Anspruche zum günstigen Preis!
In einem gut geordnetem Koffer aus Kunststoff - alles griffbereit!
